Eibach leverer 30mm TUV godkjent senkesett til 2000 corolla coupe 1.8 16V TS (ZZT231_) 192hk.
Her er det som står på norsk bildelskataolg sine sider ihvertfall:
"senket 30 mm, markeringstørelse EW 8261001 VA, markeringstørelse EW 8261002 HA, med TÜV godkjenning, for kjøretøy uten nivåregulering "
"Here all wheel/tyres-combinations are possible, which are
released by the wheel type testing institution.
The instructions in the wheel approval have to be
adhered to, except when OE suspension is required.
, Mounting - we recommend to have our spring system
installed by a qualified workshop only, which has at
disposal skilled personal and the required special tools.
Mounting position - you can "read" the mounting position
of the springs from the imprint - have them installed just
the way you read the imprint.
Anti-wheel-lock bracking system - for vehicles with load
controlled anti-wheel-lock bracking on the rear axle check
the adjustment of the system and have it readjust by your
specialist workshop if necessary.
Wheel adjustment - after completion of the spring installati
on checking the wheel adjustments is required.
Shock absorbers - if the standard shock absorbers are not
fully operative anymore and their efficiency has worn off
considerably, we strongly recommend to replace those by
NEW standard shock absorbers or by sports shock absorbers.
Lowering - the lowering we indicate refers to the stationary
height of the new vehicle.
Measurin g technique - stationary height - To obtain
comparable measured values, the influence of the
wheel/tire combination on the height to be calculated,
should be eliminated - consequently
the vertical distance from the wheel hub centre to the lower
edge of the mudguard should be compared prior
to/after conversion.
Special features for Mercedes Benz Type - if the disered
lowering is not achieved, the dimensioning of the rubber
spring plate installed by the manufacturer should be
checked and the spring plate replaced where necessary.
The rubber spring plates are available in all Daimler-
Chrysler specialist workshops in sizes 8-23 mm.
Levelling control - the levelling control should be adjusted
by a specialist workshop.
Antiskid system - by each type of vehicle with the antiskid
system it should be made sure that the sensors are being
precisley readjusted after installation.
The extension of the lowering has to be reduced by the
series lower ing."
Håper dette hjalp deg litt på vei, så gjenstår det vel for deg å finne noen som leverer Eibach i nærheten av deg.
Og her er hva H&R leverer;
" H&R Senkefjærer - 30mm - Toyota Corolla Type E10, E11, E11U, 5/92-2001. TUV-Godkjente."
